Tron.ix 2 Lab Manual goes through 39 different lessons and experiments!
(
"Basic Digital Concepts and OpAmps")
Table of Contents
- 1 .Digital vs Analog
- 2. Digital Terminology
- 3. Solderless Circuit Board Assembly
- 4. LED Logic Indicator Circuit
- 5. 'AND' Logic Gate with discrete components
- 6. 'OR' Logic Gate with discrete components
- 7. 'NOT' and 'YES' Logic Circuits
- 8. 'NOR' Logic Gate
- 9. 'NAND' Logic Gate
- 10. 2 'NAND' Logic Gate Clock
- 11. 'NAND' Logic Gate Timer
- 12. 2 'NAND' Logic Gate Memory Circuit
- 13. 555 Timer IC and formulas
- 14. Binary Counter Circuit (MOD16)
- 15. Decade Counter Circuit (MOD10)
- 16.2,4,8,16 Divider Circuit
- 17. Digital Readout LED display
- 18. Digital Readout Decoder Chip
- 19. Digital Counter with 7-Segment Display
- 20. Digital UP-DOWN Counter
- 21. 8-Output Multiplexer Circuit
- 22. Digital 'Chasing Lights' Circuit
- 23. Visual 'Logic Probe' Circuit
- 24. 'Touch-Activated' Pulse Generator
- 25. 555 Pulse Train Generator
- 26. Yes/No Decision Maker Circuit
- 27. Yes/No/Maybe Circuit
- 28. Stop-Action Timing Circuit
- 29. Digital 'Touch-Activated' Switch
- 30. Digital 'Stepping Touch-Activated' Switch
- 31. Digital 'Light-Activated' Counter Circuit
- 32. 'Winning Number' Generator
- 33. Digital Dice Circuit
- 34. Introduction to Flip-Flops
- 35. 'D' Flip-Flop circuits
- 36. 'J-K' Flip-Flops
- 37. Schmidt Trigger
- 38. Shift Registers
- 39. OP AMP Circuits
